Diamondback Yowie 3
If you're an avid trail explorer, the Yowie is the XC bike of your dreams. Designed for long rides, it offers a comfortable experience with 110mm of travel thanks to our Level Link suspension platform. Plus, the Fox 34 Performance Float fork provides an additional 130mm of travel for tackling diverse terrain.
Equipped with a SRAM GX Eagle 1×12 drivetrain, this bike offers a wide range of gears while maintaining a lightweight and smooth performance. The Shimano SLX hydraulic disc brakes ensure reliable stopping power. With 29x2.4" Maxxis tires in the front and 2.25" in the rear, you'll have excellent traction.
To enhance your adventure, the bike features a KS Rage-I dropper post, giving you the flexibility you need for various riding conditions. Meet the newest addition to the Level Link family – a short travel 29'er designed to elevate your trail riding experience.
Components and Specifications:
COMPONENT | SPECIFICATION |
---|---|
FRAME | Yowie Alloy 29" Frame, 110mm Travel, Level Link Suspension Platform, ISCG-05 Tabs, Boost 148x12mm Maxle Dropout, 1.5" Tapered Headtube |
REAR SHOCK | Fox DPS Performance Elite Float LV Evol |
FORK | Fox 34 Performance Float, 29", 130mm Travel, Grip 3 Position Dampener, Rebound Adjust, 1.5" Tapered Steerer, 110x15mm Thru-axle |
HEADSET | FSA No. 57 Sealed Cartridge |
CRANKS | SRAM Stylo 7K, 32T |
SPROCKET | 32T Aluminum |
BOTTOM BRACKET | SRAM DUB |
FRONT DERAILLEUR | N/A |
REAR DERAILLEUR | SRAM GX Eagle, 12 Speed |
SHIFTER | SRAM GX Eagle, 12 Speed |
COGSET | SRAM XG Eagle, 10-50T |
CHAIN | SRAM NX Eagle W/PowerLock |
FRONT HUB | 32h Aluminum Boost 110x15mm Thru-axle, Sealed Cartridge Bearing |
REAR HUB | 32h Aluminum Boost 148x12mm Thru-axle, 4 Sealed Cartridge Bearing, XD Cassette |
SPOKES | Stainless Steel |
RIMS | Diamondback Blanchard 28R, Taped for Tubeless, 32h |
TIRES | Maxxis Rekon 29x2.4" Front / Rekon Race 29x2.25" Rear, both Tubeless Ready |
BRAKE LEVERS | Shimano SLX |
PEDALS | DB Aluminum Platform w/Replaceable Pins |
HANDLEBAR | DB35 Aluminum 780mm Wide, 20mm Rise, 35mm Bar Bore |
GRIPS | Ergon GE10 Evo Lock-On |
STEM | DB35 Aluminum 35mm Reach, 35mm Bar Bore |
SEAT | WTB Koda Race |
SEATPOST | KS Rage-I, Internal Dropper, 31.6 w/Westy 1x Remote, Travel XS-75MM, S-100MM, MED-150MM, L-150MM, XL-170MM |
EXTRAS | Tool Kit, DB Shock Pump, DB Mud Guard, Tubeless Valves |
BRAKES | Shimano SLX M7100 |
Geometry:
FRAME SIZE | SM/15 5'4" - 5'7" | MD/17 5'7" - 5'10" | LG/19 5'10" - 6'2" | XL/21 6'2" - 6'6" |
---|---|---|---|---|
Rider Height | - | - | - | - |
Bike Stand Over Height | 730.0 mm | 730.0 mm | 738.0 mm | 740.0 mm |
Bike Seat Tube Length | 383.0 mm | 410.0 mm | 460.0 mm | 485.0 mm |
Bike Top Tube Length | 592.0 mm | 617.0 mm | 637.0 mm | 660.0 mm |
Bike Head Tube Length | 90.0 mm | 100.0 mm | 110.0 mm | 120.0 mm |
Bike Head Angle | 67.0 ° | 67.0 ° | 67.0 ° | 67.0 ° |
Bike Seat Angle | 75.0 ° | 75.0 ° | 75.0 ° | 75.0 ° |
Bike Wheel Base | 1152.0 mm | 1176.0 mm | 1199.0 mm | 1223.0 mm |
Bike Chain Stay Length | 435.0 mm | 435.0 mm | 435.0 mm | 435.0 mm |
Bike Fork Offset | 44.0 mm | 44.0 mm | 44.0 mm | 44.0 mm |
Bike Bb Height | 336.0 mm | 336.0 mm | 336.0 mm | 336.0 mm |
Bike Bb Drop | 40.0 mm | 40.0 mm | 40.0 mm | 40.0 mm |
Bike Stem Length | 35.0 mm | 35.0 mm | 35.0 mm | 35.0 mm |
Bike Handlebar Width | 780.0 mm | 780.0 mm | 780.0 mm | 780.0 mm |
Bike Crank Length | 170.0 mm | 175.0 mm | 175.0 mm | 175.0 mm |
Bike Seat Post Length | 435.0 mm | 485.0 mm | 485.0 mm | 485.0 mm |
Bike Stack | 604.0 mm | 613.0 mm | 622.0 mm | 631.0 mm |
Bike Reach | 430.0 mm | 450.0 mm | 470.0 mm | 490.0 mm |
Bike Fork Travel | 130.0 mm | 130.0 mm | 130.0 mm | 130.0 mm |
